Services | Library Development

We develop and support schematic symbols and PCB footprints meeting IPC Standards.

• PCB footprints as per the IPC-7351B
• Recommendations made in IPC-2221 or IPC-2222
• Drill tolerances as per the IPC-2615
• Footprints for Low density applications – IPC - A( Maximum )
• Footprints for Moderate applications – IPC - B (Nominal)
• Footprints for High density applications - IPC - C (Minimum)
